[CV52001/4936636]Fleetguard 2007.5-2024 6.7 liter diesel CCV crankcase breather element(OEM 68002433AB)

Crankcase Ventilation Filter CV52001 Cummins 4936636 High efficiency crankcase aerosol filtration Reduces oil consumption and environmental waste RAM TRUCK: CV52001

 Cummins Filtration's crankcase ventilation systems are innovative products using patented technologies to control oil drip and crankcase emissions in diesel engine applications. The open crankcase ventilation (OCV) systems provide superior aerosol filtering of crankcase emissions, commonly known as blow-by. Blow-by is the result of high pressure gases and oils escaping around piston rings and venting to the atmosphere. This oily mist attracts dust and airborne particles, resulting in an accumulation of contaminants, both on the engine and on the surface beneath it. This condition increases the clean-up required in the engine compartment, as well as unsightly oil drips on highways, bodies of water, parking lots, crops, garage floors and driveways.

Cummins Filtration offers a complete line of OCVs for diesel engine applications from 60 to 640 HP. Benefits of the systems include:

• Virtually eliminates oil drip
• Reduces oil consumption
• Superior aerosol filtration and collection
• Reduces engine maintenance and down time
• No service required
• System Life = Engine Life
• Warranty - 3 years

Cummins Filtration Closed Crankcase Ventilation (CCV) Retrofit Kit protects the engine and provides the best solution for emissions removal - helping to reduce oil consumption by eliminating mist, aerosol vapors and oil drip in the engine compartment.

• OEM Approved / Validated
• Filters up to 99% of oil drip from blow-by
• Filters up to 95% of aerosol vapors from blow-by
• Eliminates 100% of engine compartment fumes
• Applies to most diesel engine applications with up to 10L engine displacement (or up to 12ft³/min (340L/min) of crankcase blow-by)
• For certain OEM engines, retrofit kit can be applied to engine applications with up to 15L engine displacement
• Compact design mounts easily in engine compartment
• Up to 3 times longer service intervals than competition

For Federal/State Retrofit Funding use part number **CV51118 kit

• Environmental Protection Agency (EPA) Verified
• Verification applies when used with Cummins Emission Solutions diesel oxidation catalyst
• High efficiency coalescing filter assembly
• Crankcase Depression Regulator (CDR) Valve that regulates pressure between engine crankcase and turbocharger inlet
• CDR Valve bracket
• Oil drain-back to the engine oil sump
  ** Additional hardware (hoses, clamps, oil drain back fittings, etc.) required to complete installation.
